SKU ANT-H040
Twin Halyard Block, Sheave D39, SWL 3500 kg
Model: H040
The “Twin-halyard block” is specially made for a 2 to 1 main halyard.
The very small sheave is aluminium made with a Composite Fibre bushing. The body is completely made in “High-resistance” stainless steel Nitronic 50. 4 sizes for breaking loads from 2600 to 10000 kg, for boats up to 70 ft.
Techical Details
| ATTRIBUTE | VALUE |
|---|---|
| Overall height from deck (H) | 21 |
| Ø sheave (D) | 39 mm |
| Side bearing | Delrin balls |
| Radial bearing | composite fibre |
| Weight | 0,28 kg |
| Ø max line | 14 mm |
| A | 21 mm |
| B | 25 mm |
| C | 80 mm |
| SWL | 3500 kg |
| Material | Steel Nitronic 50 |
| Sheave material | Aluminum |
| d | 12 mm |
